AEM HIU
    发布时间: 2022-01-21 14:58

科研绘图SCI画图作图学术杂志封面设计TOC示意图文章配图医学动画

sci杂志封面设计

In the family of Zn/manganese oxide batteries with mild aqueous electrolytes, cubic α-Mn2O3 with bixbyite structure is rarely considered, because of the lack of the tunnel and/or layered structure that are usually believed to be indispensable for the incorporation of Zn ions. In this work, the charge storage mechanism of α-Mn2O3 is systematically and comprehensively investigated. It is demonstrated that the electrochemically induced irreversible phase transition from α-Mn2O3 to layered-typed L-ZnxMnO2, coupled with the dissolution of Mn2+ and OH− into the electrolyte, allows for the subsequent reversible de-/intercalation of Zn2+. Moreover, it is proven that α-Mn2O3 is not a host for H+. Instead, the MnO2 formed from L-ZnxMnO2 and the Mn2+ in the electrolyte upon the initial charge is the host for H+. Based on this electrode mechanism, combined with fabricating hierarchically structured mesoporous α-Mn2O3 microrod array material, an unprecedented rate capability with 103 mAh g−1 at 5.0 A g−1 as well as an appealing stability of 2000 cycles (at 2.0 A g−1) with a capacity decay of only ≈0.009% per-cycle are obtained.

https://doi.org/10.1002/aenm.202100962
